Rapid Mixer Granulator
₹2,260,000.00
Product Descriptions:
In the pharmaceutical industry, Rapid Mixer Granulator shows a vital role to mix the ingredients and make granules before compression. This machine is also known in Industries with various essential terms as High shear mixer granulation device, Hard Powder granulator, Wet Granulator, Pharma Stationer..
Technical Specifications:
| Model | RMG-25 | RMG-50 | RMG-100 | RMG-150 | RMG-300 | RMG-400 | RMG-600 | RMG-750 | RMG-900 | RMG-1200 |
|---|---|---|---|---|---|---|---|---|---|---|
| Gross Cap (Ltrs.) | 25 | 50 | 100 | 150 | 300 | 400 | 750 | 900 | 1200 | – |
| Working Cap. (Ltrs) | 17 | 35 | 80 | 120 | 240 | 320 | 480 | 600 | 720 | 900 |
| Main Motor (H.P.) | 3/5 | 5/7.5 | 7.5/10 | 10/15 | 20/30 | 30/40 | 40/50 | 40/50 | 40/50 | 50/60 |
| Chopper Motor (H.P.) | 1/1.5 | 1/1.5 | 2/3 | 3/5 | 3/5 | 5/7.5 | 5/7.5 | 5/7.5 | 5/7.5 | 7.5/10 |
| Width in mm | 1000 | 1050 | 1800 | 1800 | 2150 | 2400 | 2700 | 2700 | 2800 | – |
| Length in mm | 1600 | 1900 | 2200 | 2550 | 2600 | 2800 | 3000 | 3100 | – | – |
| Height H1 in mm | 1350 | 1400 | 1800 | 1800 | 2150 | 2200 | 2500 | 2600 | 2700 | 2800 |
| Height with Lid H2 in mm | 1600 | 1700 | 2500 | 2500 | 3050 | 3150 | 3500 | 3700 | 3800 | 3900 |
| Weight in Kg | 900 | 1000 | 11500 | 1700 | 2200/td> | 2400 | 2800 | 3300 | 3500 | 4000 |
Sailent Features:
Unique design incorporating Impeller, Granulator, Online Co- mill, Side discharge valve & dryer.
Ensures the round and even granules of high density. Meets cGMP requirements.
Dry and wet granulation in one step.
Detachable impeller &chopper ensure 100% cleaning.
Minimum possible gap between bottom surfaceand impeller ensures no deposition at bottom surface.
Specially mounted torque sensor arrangement forcritical parameters of granulation like end point determination & desired granule profile
Process control andinterlock through by PLC & colour touch screen HMI facility.
Automated dischargeinterlocked & interfaced with PLC.
PLC interfaced binderfeeding, WIP, Auto Powder Loading.
Description
| Capacity | 250 Liters |
We are Technic Pharma Equipments deals in Cosmetic Machine And Plant, Toothpaste Machines And Plant, Ointment Plant, SS Kettles, Fluid Bed Dryers, Tube Filling Machine, Contra Rotary Mixer, Ribbon Blender, Ointment Cream Mixer, in Mumbai, Maharashtra, India
